Industrial Roller Door

A single-skinned galvanised steel roller shutter designed to protect the building from the unwanted attentions of both the opportunist and the planned attack thief. Industrial Roller Doors are recommended for standard commercial and retail applications such as factories, warehouses and garages.

Manufacture Product Name Reference
Fleming Doors Industrial Roller Door FD-MRD-75


Designed for Industrial and Commercial application and recommended for factories / warehouses/ garages.


Interlocking galvanised steel laths 75mm in height, secured laterally by endlocks riveted to both ends on alternative laths. Bottom lath galvanised T bar.

Curtain Options

Galvanised, Powder Coated or PVC: Standard RAL or BS codes


Galvanised steel 80mm x 80mm box guides per punched


A mild steel seamless tube to;BS4760 Grade 50C. Barrel diameter and thickness engineered to specific size of opening size.


Vertical roller shutter for face / reveal fixing. Suitable for both fixing to block work and/or steel.

End Plates

The endplates for the safety brake and motor unit are manufactured from mild steel plates of varying thickness and incorporate the necessary fixing positions for securing back to the opening structure.


Standard finish is galvanised steel curtain and guides with non-galvanised components.

Door curtain, guides, end plates and canopy can be supplied BS EN 12206-1 polyester powder coated (PPC) to the Fleming Doors Colour Range of 30 No. BS and RAL colours.

Non-standard colours are available on request.

PVC curtain also available


As standard an industrial duty 3 phase or single phase chain drive motor, specified to lift curtains weight. The motor unit is prewired to a plug and a 3 station push button unit. The motor unit incorporates integral travel, safety limits and thermal cut out. The unit also includes a manual override chain device & integrated safety brake mechanism.


Maximum dimensions 6000mm x 6000mm under standard construction. Larger sizes available by specification.


  • CE marked
  • BS EN 13241 – 1 (2005)
  • Electric operated roller doors
  • (89/106/EC; 98/37/EC; 89/336/EC)


  • Key Switch
  • Key Switch Security Box
  • Remote Control Unit c/w 2 No. Handsets
  • Photocells
  • Additional Remote Handsets
  • Rubber Seal (suitable for T Bar Bottom Bar only)
  • Top Brush
  • Side Brush
  • Canopy
